Ebenezer Moravian Church

N8095 High Road
Watertown, WI 53094

Builder: Henry Robert Weiland, 1968
Originally Hinners Organ Co., Opus 662, 1905
Manuals: 1
Ranks: 11
Action: Mechanical

Notes: In 1968, the Hinners organ was renovated by Henry Weiland, replacing most though not all of the stopknobs, redecorating the façade pipes, and making many tonal changes. The Open Diapason pipes were replaced with the Principal pipes, which were replaced with another (apparently old) set. The Open Diapason and Principal are neither divided nor enclosed, nor is the pedal Bourdon. The bottom 12 pipes of the manual Bourdon are tubed off the chest and unenclosed, and both strings take their bottom octave from the Gedackt.

* Enclosed and divided at middle C (24 bass, 37 treble)

MANUAL - 1905 Hinners
16' Bourdon 61 *
8' Open Diapason 61
8' Gedackt 61 *
8' Aeoline 61 *
8' Viola d'Gamba 61 *
4' Principal 61
4' Flute 61 *
2-2/3' Quinte 61 *
2' Flautino 61 *
8' Oboe Gamba (TC) 49 *

PEDAL
16' Bourdon 27


MANUAL - 1968 Weiland
16' Bourdon 61 *
8' Open Diapason 61
8' Gedackt 61 *
8' Salicional 61 *
8' Gamba 61 *
4' Principal 61
4' Harmonic Flute 61 *
1-1/3' Larigot 61 *
2' Principal 61 *
8' Schalmei (TC) 49 *

PEDAL
16' Bourdon 27


    Tremolo
    Octave Coupler
    Pedal Coupler
    Bellows Signal
    Swell Pedal, Forte Combination, Piano Combination
