Trinity Lutheran Church

1904 Winnebago Street
Madison, WI 53704

Builder: Gayle Monette & Associates, 2004
Originally Schantz Organ Co., Opus 461, 1961
Manuals: 3
Ranks: 47
Pipes: 2,544
Action: Electropneumatic

Notes: Tonal revisions were made by Monette in 1986. The instrument was rebuilt by Monette in 1998 with additional tonal work in 2004.

GREAT ORGAN
16' Principal 29
8' Principal 61
8' Hohlflöte 61
4' Octave 61
4' Rohrgedackt 61
2' Octave 61
II-V Grand Cornet 177
IV Mixture 244
8' Trumpet (pf)

SWELL ORGAN
16' Rohrbourdon 12
8' Rohrflöte 61
8' Viole 61
8' Viole Celeste 56
4' Principal 61
4' Fugara (Viole) 12
4' Nachthorn 61
2-2/3' Nazard 61
2' Waldflöte 61
IV Plein Jeu 183
16' Fagott 61
8' Trompette 61
8' Fagott 12
4' Fagott 12
    Tremulant

CHOIR ORGAN
8' Gemshorn 61
8' Gemshorn Celeste 49
8' Gedackt 61
4' Principal 61
4' Koppelflöte 61
2-2/3' Nasat 61
2' Blockflöte 61
1-3/5' Terz 61
1-1/3' Quinte 61
III Zimbel 183
8' Krummhorn 61
    Tremulant
    Chimes
    Zimbelstern

PEDAL ORGAN
16' Principal 32
16' Subbass 32
16' Rohrbordun (Sw) 12
8' Octave 32
8' Bass Flute 12
8' Rohrflöte (Sw)
4' Choralbass 12
4' Rohrflöte (Sw)
2' Nachthorn 32
III Rauschpfeife 96
16' Posaune (pf)
16' Fagott (Sw)
8' Trompette (Sw)
8' Fagott (Sw)
4' Fagott (Sw)
