St. Francis Xavier Cathedral

140 South Monroe Avenue
Green Bay, WI 54301

Builder: Wicks Pipe Organ Co., Opus 6054, 1986
Manuals: 4
Ranks: 51
Pipes: 3282
Action: Wicks Direct Electric

Notes: This instrument incorporates a number of ranks from two Schaefer Organ Company instruments that were in the Cathedral prior to installation of the Wicks. While the Schaefer organ was being removed from the Gallery, the Wicks Company installed a 2 manual, 5 rank highly unified and duplexed organ (Opus 6055, 1985) in the front of the Cathedral. When the Gallery organ was finished in 1986, the unit organ in the front became the Antiphonal division of the organ. In 2017, Wicks Pipe Organ Co. cleaned and repaired the Gallery organ and rebuilt the console. The antiphonal organ was removed and relocated, in 2018, to Episcopal Church of the Apostles, Oro Valley, AZ.

GREAT ORGAN
16' Gemshorn 61
8' Prinzipal 61
8' Rohrflöte 61
4' Oktav 61
4' Nachthorn 61
4' Gemshorn 24 (ext)
2' Spitzflöte 61
IV Mixtur 244
III Scharf 183
16' Fanfare Trompete tc
8' Schalmei 61
8' Fanfare Trompete 61
4' Fanfare Trompete 12 (ext)
    Gt to Gt 4
    Unison Off
    Glocken 21 tubes

SWELL ORGAN
16' Bourdon 12 (ext)
8' Prinzipal 61
8' Holzedeckt 61
8' Salizional 61
8' Vox Celeste tc 49
4' Spitz Prinzipal 61
4' Hohlflöte 61
2-2/3' Nasat 61
2' Block Flöte 61
III Mixtur 183
16' Kontra Fagot 61
8' Fagot 12 (ext)
8' Trompete 61
8' Fanfare Trompete (Gt)
4' Rohr Schalmei 61
    Tremulant
    Zimbelstern
    Sw to Sw 16, 4
    Unison Off

CHOIR ORGAN
8' Gedeckt 61
8' Erzähler 61
8' Erzähler Celeste tc 49
4' Koppelflöte 61
2-2/3' Nasat 61
2' Prinzipal 61
1-3/5' Terz tc 49
1-1/3' Sifflöte 61
II Zimbel 110
8' Klarinet 61
8' Fanfare Trompete (Gt)
    Tremulant
    Chrysoglott
    Ch to Ch 16, 4
    Unison Off

ANTIPHONAL (Opus 6055)
8' Prinzipal
8' Rohrgedeckt
8' Gemshorn
8' Gemshorn Celeste tc
4' Prinzipal
4' Copula
2' Oktav
2' Gemshorn
III Mixtur
8' Trompete
4' Klarion

ANTIPHONAL PEDAL
16' Subbass
16' Lieblich
8' Prinzipal
8' Rohrgedeckt
4' Choralbass
2' Flöte
16' Kontra Trompete
4' Klarion

PEDAL ORGAN
32' Akustik Prinzipal --
16' Prinzipal 32
16' Subbass 32
16' Gemshorn (Gt)
16' Bordun (Sw)
8' Oktav 32
8' Flauten Bass 12 (ext)
8' Gemshorn (Gt)
4' Oktav 32
4' Block Flöte 12 (ext)
2-2/3' Quint 32
2' Prinzipal 32
III Mixtur 96
32' Kontra Bombard (L/2) 12
16' Bombard 32
16' Kontra Fagot (Sw)
8' Bombard (ext) 12
4' Bombard (ext) 12
8' Fanfare Trompete (Gt)
