| Builder: Moe Pipe Organ Company Manuals: 4 Ranks: 66 Action: Electro-Mechanical Sound sources: 19 ranks from existing organ (e) 7 ranks from purchased organ (p) 26 vintage ranks (v) 14 ranks purchased new (n) 30 Hauptwerk digital voices (d) --Information and photos from Allen Moe and church website Article about Holy Rosary GREAT ORGAN 16' Double Open Diapason (n) 12 pipes 16' Violoncello (d) 8' First Open Diapason (n) 61 pipes 8' Second Open Diapason (n) 61 8' Gedeckt (e) 61 8' Hohl Flute (p) 61 8' Viol (choir) 8' Viol Celeste (choir) 8' Salicional (swell) 8' Voix Celeste TC (swell) 8' Orchestral Flute (swell) 8' Flute Celeste (swell) 8' Erzahler (choir) 8' Erzahler Celeste TC (choir) 8' Dulciana (p) 61 8' Unda Maris TC (v) 49 5-1/3' Quint (d) 4' First Octave (v) 61 4' Second Octave (v) 61 4' Harmonic Flute (v) 61 4' Nachthorn (e) 61 3-1/5' Tenth (d) 2-2/3' Twelfth (d) 2' Fifteenth (n) 61 2' Flute Fifteenth (from 4') 12 1-3/5' Harmonic 17th TC (v) 37 IV Full Mixture (n) 244 III Sharp Mixture (v) 183 V Grand Cornet (derived) 16' Double Trumpet (e) 12 8' Contra Trombone (pedal) 8' Trombone (pedal) 8' Tromba (v) 61 8' Trumpet (e) 61 4' Clarion (from trumpet) 12 Chimes (p) 8' Trompette en Chamade (n) 61 8' Pontifical Trumpet (n) 61 SWELL ORGAN 16' Lieblich Gedeckt 8' Violin Diapason (p) 61 8' Stopped Diapason (p) 61 8' Harmonic Flute (cb with Stopped D) 8' Salicional (p) 61 8' Voix Celeste TC (p) 49 8' Orchestral Flute (d) 8' Flute Celeste (d) 4' Principal (v) 61 4' Harmonic Flute (n) 61 4' Lieblich Flute (p) 12 4' Violina (p) 12 2-2/3' Nazard (v) 61 2' Doublette (v) 61 2' Harmonic Piccolo (n) 12 1-3/5' Seventeenth TC (v) 37 1-1/3' Larigot 1-1/7' Septieme (v) 37 1' Piccolo 8/9' None (v) 37 IV Plein Jeu (v) 244 V Mixture (d) V Cornet (derived) 16' Waldhorn (d) 16' Basson (n) 12 8' Trompette (n) 61 8' Cornopean (d) 8' Hautbois (n) 61 8' Voix Humaine (v) 61 4' Clairon (n) 12 4' Clarion (d) 4' Hautbois Clairon (n) 12 Tremolo CHOIR ORGAN 16' Bourdon 8' Geigen Diapason (e) 61 8' Chimney Flute (e) 61 8' Copula (e) 61 8' Viol (d) 8' Viol Celeste (d) 8' Erzahler (e) 61 8' Erzahler Celeste (e) 49 4' Geigen Octave (e) 61 4' Koppel Flute (e) 12 2-2/3' Quinte (e) 61 2' Gemshorn (e) 61 1-3/5' Tierce TC (e) 37 1-1/3' Larigot (from 2-2/3') 1' Sifflote V Petite Cornet (derived) III Scharff (e) 183 II Carillon (e) 122 16' Bass Cromorne (d) 8' Tuba Mirabilis (d) 8' Orchestral Oboe (d) 8' Tuba Minor (d) 8' Corno di Bassetto (d) 8' English Horn (p) 61 8' Clarinet (v) 61 4' Tuba Clarion (d) 4' Musette (d) Zimbelstern Tremolo |
 |
   |
|
|
RESONANCE/SOLO 8' Diapasons V 8' Diapasons VIII Diapasons 8' & 4' (all 8' and 4' diapasons) 8' Solo Flutes VII String Chorus XII (strings at 16', 8' 4') Full Celestes XXVI (strings at 16', 8' 4') VIII Gross Mixture (Great mixtures 2-2/3',4') Gross Cornet XI Voix Humaine Chorus III 16' Trompette en Chamade 16' Pontifical Trumpet 8' Trompette en Chamade 8' Pontifical Trumpet 8' Tuba Magna 8' Trompetta Real 4' Trompette en Chamade 4' Pontifical Trumpet Glockenstern |
|
|
PEDAL ORGAN 64' Gravissima (d) 32' Double Open Wood (d) 32' Sub Bourdon (d) 32' Contra Violone (d) 16' Open Diapason (n) 12 16' Contrabass (great) 16' Subbass (great) 12 16' Bourdon (e) 32 16' Violone (d) 16' Violoncello (great) 16' Dolce Bass (ex) 16' Lieblich Gedeckt (swell) 12 10-2/3' Sub Quint 8' Open Bass (great) 8' Octave (e) 32 8' Bourdon (great) 8' Cello (swell) 8' Stopped Flute (choir) 8' Stopped Diapason (swell) 8' Melodia (great) 5-1/3' Quint 4' Choral Bass (v) 32 4' Viol (swell) 4' Harmonic Flute (great) 5-1/3' Full Mixture IV (great) V Sharp Mixture (v) 160 32' Double Trombone (d) 32' Contra Bombarde (d) 16' Bombarde (d) 16' Double Trumpet (great) 16' Posaune (great) 16' Waldhorn (swell) 16' Basson (swell) 8' Tromba (n) 12 8' Trumpet (great) 8' Trompette (swell) 4' Clarion (n) 12 4' Hautbois (swell) 4' Musette (choir) |
|
